C-shaped steel

C-shaped steel is a type of cold-formed thin-walled steel. It is made from hot-rolled galvanized steel strips or black steel strips, and is formed through a continuous rolling and bending process by a professional cold-forming machine. The cross-section is in a standard "C" shape, making it the mainstream type of steel for lightweight construction in structural engineering. Compared to traditional channel steel, it is lighter in weight, has higher forming accuracy, and is easier to install. It is widely used as roof trusses, columns, supports, and equipment bases.
$0.00
type:
C100*50*20*2.25
C100*50*20*2.50
C100*50*20*2.75
C100*50*20*3.00
C120*50*20*2.25
C120*50*20*2.75
C120*50*20*3.00
C140*50*20*2.50
C140*50*20*3.00
C140*60*20*2.50
C140*60*20*3.00
C160*50*20*2.50
C160*50*20*3.00
C160*60*20*2.50
C160*60*20*3.00
C160*70*20*2.50
C160*70*20*3.00
C180*50*20*2.50
C180*50*20*3.00
C180*60*20*2.50
C180*60*20*3.0
C180*70*20*2.50
C180*70*20*3.0
C180*80*20*2.50
C180*80*20*3.0
C200*50*20*2.5
C200*50*20*3.0
C200*60*20*2.5
C200*60*20*3.0
C200*70*20*2.5
C200*70*20*3.0
C200*80*20*2.5
C200*80*20*3.0
C220*50*20*2.5
C220*50*20*3.0
C220*60*20*2.5
C220*60*20*3.0
C220*70*20*2.5
C220*70*20*3.0
C220*80*20*2.5
C220*80*20*3.0
C240*50*20*2.5
C240*50*20*3.0
C240*60*20*2.5
C240*60*20*3.0
C240*70*20*2.5
C240*70*20*3.0
C240*80*20*2.5
C240*80*20*3.0
C80*50*20*2.25
C80*50*20*2.50
C80*50*20*2.75
C80*50*20*3.00
For more specifications
  • C-shaped steel
  • C-shaped steel
  • C-shaped steel
  • C-shaped steel
  • C-shaped steel
  • C-shaped steel
  • C-shaped steel

Description

Production process
After the steel strips are unwound and flattened, they are gradually bent and formed through multiple sets of rollers. Pre-installed bolt installation holes are made by stamping. The finished product can be cut to the required length as needed.
Main surface treatments are divided into two types:
Galvanized C-shaped steel: Hot-dip galvanizing / galvanized strip, rust-proof and corrosion-resistant, preferred for outdoor factories;
Black material C-shaped steel: Bare steel material, can be painted or coated with anti-rust paint later, mostly used for indoor load-bearing structures.
III. Common Specifications and Materials
Conventional specifications: C80, C100, C120, C140, C160, C180, C200, C220, C250, C300, etc. The numbers represent the cross-sectional height; the wall thickness is 1.2–3.0mm and can be customized;
Standard materials: Q235B, good toughness, easy to process; high-load conditions can choose Q355B high-strength material.
IV. Core Advantages
Light self-weight, strong bearing capacity: Thin-walled hollow cross-sectional structure, compared with channel steel, it saves steel under the same load, reduces the overall load of the building, and reduces the foundation cost;
Corrosion-resistant and durable: The galvanized layer isolates moisture and rain, the factory roof and wall can be used outdoors for a long time without rusting, and the service life can reach more than 15 years;
Efficient construction: Factory-prepared pre-pressed connection holes, no need for secondary drilling at the site, bolts are directly connected, significantly shortening the steel structure installation period;
Precise dimensions: Good flatness and straightness of cold bending forming, small joint gaps between components, higher flatness of roof and wall;
Strong plasticity: Can be cut to the required length, adjust the opening position, and adapt to various non-standard supports for factory buildings, photovoltaic systems, electromechanical equipment, etc.
V. Main Application Scenarios
Steel structure factory buildings: Roof C battens, wall C battens, combined with color steel tiles to form a protective system;
Photovoltaic projects: Main beams, secondary beams, ground anchors, cross braces of photovoltaic power stations, widely used in outdoor photovoltaic power stations;
Building accessories: Curtain wall keels, stair supports, door and window reinforcement frames;
Electromechanical equipment: Cable tray bases, equipment racks, pipe fixing supports;
Small steel structures: Simple warehouses, car sheds, greenhouse sheds for load-bearing frames.
VI. Differences from ordinary channel steel
C-shaped steel is cold-bent thin-walled, lightweight, with flanges to enhance bending resistance, mainly used for protective and supporting lightweight loads; channel steel is hot-rolled thick-walled, heavier self-weight, mostly used for large-load main beams, equipment bases, etc. The working conditions of the two are clearly distinguished.

Key attributes

Standard GB
Grade Q325
Shape C Channel
length 6m-12m
Tolerance ±1%
Brand Name ZTDX
Place of Origin Tianjin,China
Delivery Time 15-21 days
Application supportive system
Processing Service Welding, Punching, Cutting, Bending
You can contact us to obtain more product lists.


Product Advantages

Unmatched Manufacturing Expertise
As a professional steel pipe manufacturer with over a decade of experience, Tianjin Zhongtong Dingxing ensures every C-shaped steel channel meets international standards. Our expertise in square steel tubing production and galvanizing technology gives our products a competitive edge in both quality and reliability.

Durability in Challenging Environments
Thanks to our advanced hot-dip galvanizing process, our galvanized steel square tube products offer exceptional resistance to corrosion, making them suitable for use in marine, industrial, and agricultural environments. The zinc coating protects the steel core from moisture, chemicals, and physical wear.

Customizable Solutions for Every Project
Our production flexibility allows us to supply standard square hollow steel tubing as well as customized profiles to fit specific structural needs. From thickness and length adjustments to complex punching patterns, we deliver solutions that perfectly match project requirements.

Global Supply Capability with Fast Delivery
Strategically located in Tianjin Daqiuzhuang, our facility benefits from excellent logistics connections. This enables us to fulfill large-volume wholesale steel pipe orders efficiently, ensuring on-time delivery to international markets while maintaining competitive pricing.



Usage Scenarios

Construction and Infrastructure Projects
Our C-shaped square steel tubing is widely used in building frameworks, roofing structures, and wall supports, providing stability and load-bearing capacity for modern architectural designs.

Solar Panel Mounting Systems
The high strength and corrosion resistance of our galvanized steel square tube make it ideal for solar mounting systems that must endure long-term exposure to outdoor environments.

Industrial and Mechanical Frameworks
Factories and workshops use our square hollow steel tubing for machinery frames, shelving systems, and heavy-duty storage racks due to its excellent mechanical strength and adaptability.

Agricultural and Outdoor Installations
From greenhouse structures to fencing systems, our wholesale steel pipe products deliver lasting performance in agricultural settings where moisture and soil contact are common.

Transportation and Logistics Support Structures
C-shaped channels are also used in truck beds, cargo frameworks, and shipping container reinforcements, offering strength without excessive weight.


c shape channelc shape beamc shaped steel channelC Beam ProfileCarbon SteelAISI standard、ASTM A36、Q235、Q345、S355j2、S355K2Perforated Steel C Channel、Slotted C Channel、Punched C Channel41x21、41x41、100mm、125mm、200mm、5#、40#Building Materials
